CB401-VA
CB401-VA, a 4U GPGPU server, supports dual 5th Gen Intel® Xeon® Scalable Processors and 4th Gen Intel® Xeon® Scalable Processors, 12 hot-swappable drive bays (4 x NVMe + 8 x SAS/SATA), maximum 8 dual-slot GPGPU cards with up to 450W each, ideal for GPGPU applications.
KEY FEATURE
4U 8 GPU server supports maximum 8 dual-slot GPU cards with up to 450W each
FEATURE
4U 8 GPU server supports maximum 8 dual-slot GPU cards with up to 450W each
Supports Dual 5th Gen Intel® Xeon® Scalable Processors (Emerald Rapids CPU)
FEATURE
Supports Dual 5th Gen Intel® Xeon® Scalable Processors (Emerald Rapids CPU)
Supports Dual 4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids CPU)
FEATURE
Supports Dual 4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids CPU)
Supports 16 x DDR5 memory DIMM
FEATURE
Supports 16 x DDR5 memory DIMM
4 x NVMe + 8 x SAS/SATA hot swappable drive bays
FEATURE
4 x NVMe + 8 x SAS/SATA hot swappable drive bays
Specification
SPECIFICATION
Main
Sub
Details
Dimensions
mm
435 x 830 x 175
inches
17.1 x 32.7 x 6.9
Motherboard
AIC Server Board Vega
Processor
Processor Support
• 5th Gen Intel® Xeon® Scalable Processors (Emerald Rapids CPU)
• 4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids CPU)
• 4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids CPU)
CPU Interconnection
16/20GTs
Socket Type
Socket E1 (LGA-4677-X)
Chipset Support
Intel® C741
System Memory
• DDR5 5600/4800MHz RDIMM (1DPC)
• Total 16 memory slots; 8 slots per CPU (1DPC)
• Support up to 4TB (3DS RDIMM)
• Total 16 memory slots; 8 slots per CPU (1DPC)
• Support up to 4TB (3DS RDIMM)
Front Panel
System power on/off, System reset, ID button
LEDs
Power status, Drive activity, LAN activity, System alert, System ID
Drive Bays
External
3.5" hot swap x 12
Internal
2 x M.2/M-Key/2280 (PCIe Gen4)
Backplane
• 1 x 4-port PCIe Gen4 NVMe backplane
• 2 x 4-port SAS/SATA backplane
• 2 x 4-port SAS/SATA backplane
Expansion Slots
PCIe 5.0
• 3 x PCIe x16 slots (HHHL)
• 1 x PCIe x8 slot (HHHL)
• 2 x PCIe x16 slots occupied by retimer cards
• 1 x PCIe x8 slot (HHHL)
• 2 x PCIe x16 slots occupied by retimer cards
PCIe 4.0
• 8 x16 slots (FHFL)/ dual slot
• 2 x16 slots (FHHL)
• 2 x16 slots (FHHL)
System BIOS
BIOS Type
AMI UEFI BIOS
BIOS Features
• ACPI
• PXE
• WOL
• AC loss recovery
• IPMI 2.0 KCS mode interface
• SRIOV
• SMBIOS
• TPM
• Serial console redirection
• PCIe hot plug
• PXE
• WOL
• AC loss recovery
• IPMI 2.0 KCS mode interface
• SRIOV
• SMBIOS
• TPM
• Serial console redirection
• PCIe hot plug
On-board Devices
SATA
Emmitsburg PCH on-chip solution
• 1 x Slimline connector (up to 8 SATA ports)
• 1 x Slimline connector (up to 8 SATA ports)
IPMI
Aspeed AST2600 Advanced PCIe Graphics & Remote Management Processor
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• HTML5
• Redfish
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• HTML5
• Redfish
Network Controllers
• Realtek RTL8211FS 1GbE for BMC dedicated management port
• Broadcom BCM5720 dual port 1GbE (NCSI for share NIC)
• Broadcom BCM5720 dual port 1GbE (NCSI for share NIC)
Graphics
• Integrated VGA support by ASPEED AST2600
• Resolution up to 1920x1200 @60Hz 32bpp
• Resolution up to 1920x1200 @60Hz 32bpp
Rear I/O
LAN
• 1 x RJ45 GbE connector for BMC dedicated management port
• 2 x RJ45 1GbE connectors
• 2 x RJ45 1GbE connectors
USB
4 x USB 3.2 Gen 1 Type A
Video Output
1 x DB-15 VGA connector
Serial Port
Power Supply
• 2000W 3+1 redundant power supply 80+ Platinum
• 3200W 2+2 redundant power supply 80+ Titanium
• 3200W 2+2 redundant power supply 80+ Titanium
System Cooling
9 x 80x56mm easy swap fans
System Management
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• SMASH Support
• HTML5
• Redfish
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• SMASH Support
• HTML5
• Redfish
Environmental Specifications
• Storage temperature: -10°C(14°F) ~ 60°C(140°F)
• Operating temperature: 0°C(32°F) ~ 35°C(95°F)
• Storage operating humidity: 5%~95% non-condensing
• Operating temperature: 0°C(32°F) ~ 35°C(95°F)
• Storage operating humidity: 5%~95% non-condensing
Gross Weight (W/PSU& Rail)
kgs
43.5
lbs
95.9
Packaging Dimensions (W x D x H)
mm
625 x 1130 x 454
inches
24.6 x 44.5 x 17.9
Mounting
Standard : 43” tool-less slide rail
* All specifications are subject to change without notice.
| SKU Information | Description |
|---|---|
| XP1-C401VA01 | 4U 12-bay 8 GPU/FPGA server, 4x 3.5"/2.5" NVMe/SAS/SATA + 8x 3.5"/2.5" SAS/SATA hot-swap (Passive BP), 2000W 3+1 Platinum redundant power supply, 9x 8056 easy-swap fan, FIO Vega motherboard, Intel 5th /4th Gen Xeon, DDR5 RDIMM x16, Intel Emmitsburg PCH (C740), 1 x GbE dedicate IPMI, 4x PCIe x16 HHHL Gen.5 (front), 1x PCIe x8 HHHL Gen.5 (front), 2x PCIe x16 FHHL Gen.4 (rear), 8x PCIe x16 FHFL/dual slot Gen.4 (rear), EATX, 2x active CPU heatsink (250W), 37" slide rail, w/o bezel |
| XP1-C401VA02 | 4U 12-bay 8 GPU/FPGA server, 4x 3.5"/2.5" NVMe/SAS/SATA + 8x 3.5"/2.5" SAS/SATA hot-swap (Passive BP), 3200W 2+2 Titanium redundant power supply, 9x 8056 easy-swap fan, FIO Vega motherboard, Intel 5th /4th Gen Xeon, DDR5 RDIMM x16, Intel Emmitsburg PCH (C740), 1 x GbE dedicate IPMI, 4x PCIe x16 HHHL Gen.5 (front), 1x PCIe x8 HHHL Gen.5 (front), 2x PCIe x16 FHHL Gen.4 (rear), 8x PCIe x16 FHFL/dual slot Gen.4 (rear), EATX, 2x active CPU heatsink (250W), 37" slide rail, w/o bezel |
