XC-12T (NVMe)
This drive enclosure converts 1 x 5.25 drive bay to 2 x 2.5 SFF hot swap bays, supporting 2 NVMe PCIe SSDs. The drive trays are tool-less. No tools are needed for installation and removing of drives.
Specification
SPECIFICATION
Main
Sub
Details
Dimensions
mm
148 x 165 x 41.7
inches
5.8 x 6.5 x 1.6
Material
Heavy-duty preplated SPGC cold-rolled steel
Finish
Front Panel : Texture-coated
Cooling
LED Indicators
Drive
Drive Bays
External : 2 x 2.5”
Backplane
1 x 2-port NVME backplane with 2 SFF-8643 connectors
* All specifications are subject to change without notice.
| SKU Information | Description |
| XE1-12T00-00 | 5.25" to 2x 2.5" canister cage with package, 2-port NVMe PCIe Gen.3 backplane |
| XE1-12T00-01 | 5.25" to 2x 2.5" canister cage with package, 2-port NVMe PCIe Gen.3 backplane, with 8643*2 port PCIe 8x card 1 pcs, 8643 to 8643 cable 2 pcs |
| XE1-12T00-02 | 5.25" to 2x 2.5" canister cage with package, 2-port NVMe PCIe Gen.3 backplane, with 8643*2 port PCIe 8x card 2 pcs, 8643 to 8643 cable 2 pcs |
| XE1-12T00-03 | 5.25" to 2x 2.5" canister cage with package, 2-port NVMe PCIe Gen.3 backplane, with 8643*2 port PCIe 8x card 1 pcs |
