SB407-ID

SB407-ID, a 4U high-density server designed for large-scale storage and data-intensive applications. It provides 60 hot-swappable 3.5" bays. The rear supports 6 NVMe PCIe Gen5 and 2 SATAIII 2.5" hot-swap drives, offering a flexible multi-tier storage architecture. With 6 PCIe Gen5 x16 slots, the system delivers extensive expansion for high-speed networking or additional storage connectivity. Powered by a 1600W 1+1 Titanium CRPS and designed for dual-CPU cooling, the SB407-ID provides reliable, scalable performance for modern enterprise applications.

COMPARE REQUEST A QUOTE DOWNLOAD

Specification

Specification
SKU

SPECIFICATION

Main

Sub

Details

Dimensions

434 x 853 x 176

inches

17.1 x 33.6 x 7

Motherboard

AIC Server Board Indus

Processor

Processor Support

• Dual 6th Gen Intel® Xeon® Scalable
• Supports CPU TDP 350W
*Please contact AIC Technical Support for more info/details about optimized CPUs and specialized system.

CPU Interconnection

16/20/24GTs

Socket Type

Socket E2 (LGA 4710 Socket)

Chipset Support

System Memory

• DDR5 6400MHz RDIMM (1DPC)
• DDR5 8000MHz (1DPC MCR)
• Total 16 memory slots; 8 slots per CPU (1DPC)
• Supports up to 4TB (3DS RDIMM)

Front Panel

System power on/off, System reset, 1 x USB 3.2 Gen1 Type-A

LEDs

Power status, System alert, LAN activity, Drive activity, System ID

Drive Bays

External

• 3.5" hot swap x 60

• 2.5" hot swap x 8 (6 NVMe Gen5 + 2 SATA)

Internal

2 x M.2/M-Key/2280 PCIe Gen5 x4

Backplane

Top-load:

2 x 30-port 12G SAS BP with 40-PHY expander

Rear:

8-bay Gen5 Tri-mode config as 6 NVMe + 2 SATA

Expansion Slots

PCIe 5.0

6 x PCIe x16 slots

PCIe 4.0

Expander Board

System BIOS

BIOS Type

AMI UEFI BIOS

BIOS Features

• ACPI
• PXE
• AC loss recovery
• IPMI KCS interface
• SMBIOS
• Serial console redirection
• SRIOV
• TPM (optional)
• PCIe hotplug

On-board Devices

SATA

• 2 x SATA 7-pin
• 8 x SATA by 1 slimline connector

IPMI

Aspeed AST2600 Advanced PCIe Graphics & Remote Management Processor
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• HTML5
• Redfish
• SMASH Support

Network Controllers

Dual ports 1GbE LANs by BRCM5720 Realtek RTL8211FS for BMC dedicated management port

Graphics

Aspeed AST2600 Advanced PCIe Graphics & Remote Management Processor
• PCIe Graphic/2D Controller
• 1920x1200@60Hz 32bpp

Rear I/O

LAN

• 1 x RJ45 GbE connector for BMC dedicate management port
• 2 x RJ45 1GbE connectors

USB

2 x USB 3.2 Gen1 Type-A

Video Output

1 x DB-15 VGA connector

Serial Port

1 x phone jack

Other(s)

Power Supply

1600W 1+1 CRPS Titanium

System Cooling

Standard：4 x 80x38mm fans

Optional：2 x 60x38mm fans

System Management

• IPMI 2.0
• KVM over IP
• Media redirection
• Temperature, fan, voltage, PSU sensor monitor
• System temperature
• System ID / System fail indicator
• Remote power on/off/reset
• SEL message alarm through mail
• SNMP support

Environmental Specifications

• Storage temperature : -10ºC(14ºF) ~ 60ºC(140ºF)
• Operating temperature : 0ºC(32ºF) ~ 35ºC(95ºF)
• Storage operating humidity : 5%~95% non-condensing

Gross Weight (W/PSU& Rail)

kgs

lbs

176

Packaging Dimensions (W x D x H)

586 x 1110 x 400

inches

23 x 43.7 x 15.7

Mounting (Standard)

Options :

• 40” tool-less slide rail

• 37” tool-less slide rail

• Cable management kit

* All specifications are subject to change without notice.

SKU Information	Description
XP1-S407ID01	4U 60x3.5" H/S SATA/SASIII, 35X EOB SAS3 backplane, rear 6-bay NVMe PCIe(Gen5) + 2-bay 2.5" SATAIII hot-swap, Indus motherboard, 16x DDR5 slots (up to 32GB per DIMM), 2x active CPU heatsinks (CPU TDP up to 250W), 4x8038 + 2x6038 fans, 1600W 1+1 Titanium PSU, 28" slide rail (for 1M rack), w/o bezel
