J4060-04-35X
KEY FEATURE
4U high-density JBOD supports 60 hot-swap 3.5” SAS/SATA drive bays
FEATUREIPMI compliance BMC Intelligent Enclosure Management
FEATUREHot swap design for maintenance and management
FEATUREEnclosure Cable Management Kit
FEATUREOptimized for 1000mm Depth Rack-mount Server Cabinet
FEATURESPECIFICATION
General
Drivers Supported
Administration/Management
• IEM port (Optional)
Hot Swap and Redundancy
• 1200W 1+1 80+ Platinum
• 1300W 1+1 80+ Titanium
Electrical and Enviromental
Platinum/Titanium 800W:
• 100~127V~, 50/60Hz, 10A
• 200~240V~, 50/60Hz, 5A
Platinum 1200W:
• 100~127V,50/60Hz,10A; Total Power 800W
• 200~240V,50/60Hz,8A; Total Power 1200W
Titanium 1300W:
• 100-127V~,50/60Hz,12A
• 200-240V~,50/60Hz, 8.5A
• Relative humidity 20% to 80%
• Relative humidity 10% to 90%
Physical Specification
• inches: 17.1 x 29.5 x 6.9
• lbs: 128.3
• inches: 25.6 x 44.9 x 20.9
Mounting
• Option: Cable Management Kit
* All specifications are subject to change without notice.
| Ordering Information | Description |
|
XJ1-40604-01 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with single SAS 12G expander controller, single BMC, tool-less HDD tray,800W 1+1 hot-swap redundant 80+ Platinum, tool-less rail kit (35X series) |
|
XJ1-40604-02 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with dual SAS 12G expander controller, dual BMC, tool-less HDD tray,800W 1+1 hot-swap redundant 80+ Platinum, tool-less rail kit (35X series) |
|
XJ1-40604-03 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with single SAS 12G expander controller, single BMC, tool-less HDD tray,800W 1+1 hot-swap redundant 80+ Titanium, tool-less rail kit (35X series) |
|
XJ1-40604-04 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with dual SAS 12G expander controller, dual BMC, tool-less HDD tray,800W 1+1 hot-swap redundant 80+ Titanium, tool-less rail kit (35X series) |
|
XJ1-40604-05 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with single SAS 12G expander controller, single BMC, tool-less HDD tray,1200W 1+1 hot-swap redundant 80+ Platinum, tool-less rail kit (35X series) |
|
XJ1-40604-06 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with dual SAS 12G expander controller, dual BMC, tool-less HDD tray,1200W 1+1 hot-swap redundant 80+ Platinum, tool-less rail kit (35X series) |
|
XJ1-40604-07 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with single SAS 12G expander controller, single BMC, tool-less HDD tray,1300W 1+1 hot-swap redundant 80+ Titanium, tool-less rail kit (35X series) |
|
XJ1-40604-08 |
4U 60x 3.5” hot-swap bays, hot-swap JBOD with dual SAS 12G expander controller, dual BMC, tool-less HDD tray,1300W 1+1 hot-swap redundant 80+ Titanium, tool-less rail kit (35X series) |
| FRU Parts | Description |
| M06-00395-15 | J4078/J4108/J4060-04/RSC-4H1/SB407/SB405 FRU parts-3.5" tray assy |
| H5532T100006 | Tool-less rail kit |
| H54-00010-34 | Cable arm/2BA7-363 (for J4060-04/J4078-01/J4078-02) |
| M15-1587-003 | Cable management kit(cable arm w/ adapter for 1M Rack use) |
| M06-00628-15 | J4060-04/J4078/J4108/RSC-4H1/SB407-TU/SB405-VL FRU parts- 3.5" tray to 2.5" device adapter (32pcs in package) |
| H18-00628B01 | 2.5 BKT only |
| M06-1339-013 | Expander module with packing (12 pcs in packing) |
| M06-1587-900 | Expander dummy cover with packing (20 pcs in packing) |
| PM-A00000117 | 800W redundant power supply module(80+ Platinum) |
| PM-A00000132 | 800W redundant power supply module(80+ Titanium) |
| PM-A00000118 | 1200W redundant power supply module(80+ Platinum) |
| PM-B00000133 | 1300W redundant power supply module(80+ Titanium) |
