ES1-208-S0
The ES1-208-S0 delivers flexible storage in a compact 580 mm short-depth 2U chassis. Supporting CEB/ATX and micro-ATX motherboards, it features 8 hot-swappable 3.5-inch drive bays plus 2 internal 2.5-inch rear drive bays. Tool-less design and optimized airflow simplify maintenance while ensuring reliable cooling for continuous enterprise operation.
KEY FEATURE
Max. 800W CRPS redundant PSU or 650W single power
FEATUREMax. 800W CRPS redundant PSU or 650W single power
Support MB up to CEB 12”(W) x 10.5”(D)
FEATURESupport MB up to CEB 12”(W) x 10.5”(D)
External 8 x 3.5"/2.5" hot-swap tray, internal 2 x 2.5"
FEATUREExternal 8 x 3.5"/2.5" hot-swap tray, internal 2 x 2.5"
2U 22.8" depth server storage
FEATURE2U 22.8" depth server storage
Specification
SPECIFICATION
Main
Sub
Details
Dimensions
mm
438 x 580 x 87
inches
17.2 x 22.8 x 3.4
Industry Standard
EIA-RS310D
Material
SGCC
Color
Front Panel: Black
Cooling
3 x 80x38mm hot swap fans
Power Supply
•550W 2U 1+1 redundant PSU 80+ Platinum
•550W 2U single PSU
• Option: 800W 2U 1+1 redundant PSU 80+ Platinum
•550W 2U single PSU
• Option: 800W 2U 1+1 redundant PSU 80+ Platinum
Expansion Slots
7 low profile
Front Panel
System power on/off, System reset, System ID and
2 x USB 3.2 Gen1 x1 ports
2 x USB 3.2 Gen1 x1 ports
LED Indicators
Power, ID, LAN 1, LAN 2, Drive, and Alert
System board
Up to CEB 12"(W) x 10.5"(D)
Drive Bays
External
• 8 x 3.5” hot swap
• 2 x 2.5” hot swap (rear, optional)
• 2 x 2.5” hot swap (rear, optional)
Internal
2 x 2.5”
Backplane
Front :
• 1 x 8-port SAS3/SATA
• 1 x 12-port SAS3/SATA/PCIe Gen4 NVMe Tri-mode
Rear :
• 1 x 2-port SATA
• 1 x 2-port SAS3/SATA/PCIe Gen5 NVMe Tri-mode
• 1 x 8-port SAS3/SATA
• 1 x 12-port SAS3/SATA/PCIe Gen4 NVMe Tri-mode
Rear :
• 1 x 2-port SATA
• 1 x 2-port SAS3/SATA/PCIe Gen5 NVMe Tri-mode
Storage Temparature
0ºC(32ºF) ~ 50ºC(122ºF)
Humidity
5%~95% non-condensing
Gross Weight (W/PSU& Rail)
kgs:
20
lbs:
44
Packaging Dimensions (W x D x H)
mm
620 x 800 x 274
inches
24.4 x 31.5 x 10.8
Cubic Feet
5.38
Container Load Quantity
20'
200
40'
420
40' H
450
Mounting
28” tool-less slide rail
* All specifications are subject to change without notice.
| SKU Information | Description |
|---|---|
| XE1-208S0-01 | 8-port 3.5" SAS/SATA, 2x internal 2.5" bay, 3x 8038 fan, 550W redundant power supply Platinum, rail |
| XE1-208S0-02 | 8-port 3.5" SAS/SATA, 2x internal 2.5" bay, 3x 8038 fan, 800W redundant power supply Platinum, rail |
