SB101-TU

SB101-TU, a 1U 4-bay storage server solution.
It supports 3rd Gen Intel® Xeon® Scalable Processors with PCIe 4.0 extension design. It has Rackmount Technology Extension (RTX) form factor utilizes and Onboard Baseboard Management Controller for system management and IPMI control.

比較索取報價相關資源下載

KEY FEATURE

特色

Supports 3rd Gen Intel® Xeon® Scalable Processors for highest server performance and improved power efficiency

特色

Supports 16 DDR4 DIMM slots for maximum memory performance

特色

Supports up to 2 x16 lanes, 4 slimline x8, 1 OCP 3.0 of PCIe Gen4 expansions

特色

Onboard Baseboard Management Controller for system management and IPMI control

特色

Embedded components for 5+ year long life

規格

規格
SKU
FRU

規格

Main

Sub

Details

Dimensions

438 x 678.7 x 44.4

inches

17.2 x 26.7 x 1.7

Motherboard

AIC Server Board Tucana

Processor

Processor Support

• 3rd Gen Intel® Xeon® Scalable Processors (Ice Lake)

• Supports CPU TDP up to 270W

CPU Interconnection

UPI Speeds: 10.4 / 11.2 GT/s

Socket Type

Socket P+ (LGA-4189)

Chipset Support

Intel® C621A Chipset

System Memory

• 8 x memory channels per CPU (1DPC)

• 16 x DIMM slots support:

DDR4 3200/2933MHz RDIMM/LRDIMM

- up to 512GB RDIMM SRx4 (16Gb)

- up to 1024GB RDIMM DRx4 (16Gb)

- up to 4096GB RDIMM 3DS 8Rx4 (16Gb)

- up to 2048GB LRDIMM QRx4 (16Gb)

- up to 4096GB LRDIMM 3DS 8Rx4 (16Gb)

• Intel® Optane™ DC Persistent Memory (Barlow Pass) support

Front Panel

• System power on/off

• System reset

• 2 x USB 3.0 Type A

• System ID

LEDs

• Power status

• HDD activity

• LAN activity

• Warning

• System ID

Drive Bays

External

3.5”/2.5” hot-swap x 4 (SAS/SATA/NVMe)

Internal

• 2 x 2.5” OS (SATA)

• M.2 : 2 x M.2(NGFF)/M-Key/2280

Backplane

1 x 4-port SATA/SAS/NVMe backplane with 1 x SFF-8643 + 2 x SFF-8654 (Slimline 8i) connectors

Expansion Slots

CPU0: 2 x PCIe Gen4 x16 slots (1 x FHHL & 1 x HHHL) + 1 x OCP V3.0

System Bios

Bios Type

AMI UEFI BIOS

Bios Features

• ACPI
• PXE
• AC loss recovery
• IPMI KCS interface
• SMBIOS
• Serial console redirection
• SRIOV
• TPM
• PCIe Hotplug

On Board

Devices

SATA :
Lewisburg PCH on-chip solution supports 10 x SATA 6.0 Gb/s
• 2 x SATA 7pin
• 8 x SATA by slimline
(supports both SATA/PCIe by PCH HSIO)

Devices BMC

Aspeed AST2500 Advanced PCIe Graphics & Remote Management Processor
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• SMASH Support
• HTML5
• Redfish

Devices Network Controllers

• Realtek RTL8211E GbE for BMC dedicated management port
• Intel I210 GbE for BMC shared NIC management port by onboard connector
(NCSI shared NIC - reserved for OCP V3.0)

Devices Graphics

Aspeed AST2500 Advanced PCIe Graphics & Remote Management Processor
• PCIe VGA/2D Controller
• 1920x1200@60Hz 32bpp

Rear I/O

LAN

1 x GbE RJ45 dedicated to BMC management

USB

2 x USB 3.0 double-stack Type A connectors

Video Output

1 x VGA DB15

Serial Port

1 x external COM port phone jack

TPM Support

2.0 onboard

Power Supply

750W/1100W 1+1 redundant power supply 80+ Platinum

System Cooling

• 6 x 40x56mm easy swap fans

• 1 x 40x28mm fan

System Management

IPMI: Aspeed AST2500 Advanced PCIe Graphics & Remote Management Processor

• Baseboard Management Controller

• Intelligent Platform Interface 2.0 (IPMI 2.0)

• iKVM, Media Redirection, IPMI over LAN, Serial over LAN

• SMASH Support

• HTML5, Redfish

Environmental Specifications

• Storage temperature: -10°C(14°F) ~ 60°C(140°F)

• Operating temperature: 0°C(32°F) ~ 35°C(95°F)

• Storage operating humidity: 5%~95% non-condensing

Gross Weight (W/PSU& Rail)

kgs

lbs

Packaging Dimensions (W x D x H)

615 x 1025 x 274
